Power Asymmetirc LED 3838 150°x90°

With its asymmetric lens design, it's tailored for Occupancy Monitor Systems and security applications, ensuring optimal performance in critical scenarios.

사양

SL3838F85CQ01

제품 유형

IR LED

치수 (L x W x H)

3.85 x 3.85 X 1.9 mm

작동 온도

-40° ~ 125℃

빔 각도

150 x 90 °

밝기

전기

복사 강도 (IE)

420 mW/sr

순방향 전류 (IF)

Typ. 1000 mA

총 복사 플럭스 (ΦE)

1360 mW

전력

Typ. 3 W

파장 (λP)

850 nm

전압 (vF)

3.25 V

혜택

  • An AEC Q102 Qualified solution, featuring low thermal resistance (Max. 9 K/W), 2kV ESD protection (HBM: MIL STD 883 Class 2), and a corrosion robustness

기능

IR light source with high efficiency

Peak wavelength 850 nm

Dual junction emitter

RoHS 2.0 and REACH compliant

MSL 2 qualified according to J STD 020
