Power Dome LED 2720 80°
Power Dome LED 2720 80°
IR 2720-B.png
IR 2720-C.png

Power Dome LED 2720 80°

Power Dome IR LED 2720은 최신 노트북 카메라 사양을 충족하며, 뛰어난 조명 균일성을 통해 인식 정확도를 향상시켜 차세대 NB 카메라 애플리케이션 요구를 만족합니다.

제품 성능

품번

파장 (λP)

전력

순방향

전류 (IF)

광속 (ΦE)

복사 강도(IE)

전압(vF)

EC27201F94CE0401

940 nm

3.6 W

1000 mA

900 mW

450 mW/sr

2.8 V

80 °

EC27201F94CE0402

940 nm

3.6 W

1000 mA

700 mW

400 mW/sr

2.6 V

80 °

EC27201F94CE0403

940 nm

3.6 W

1000 mA

700 mW

400 mW/sr

2.6 V

80 °

제품 정보

혜택

  • Power Dome IR LED 2720은 최신 노트북 카메라 사양을 충족하며, 뛰어난 조명 균일성을 통해 인식 정확도를 향상시켜 차세대 NB 카메라 애플리케이션 요구를 만족합니다.

기능

IR light source with high efficiency

Peak wavelength 940 nm

Dual junction emitter

RoHS 2.0 and REACH compliant

MSL 1 qualified according to J STD 020

애플리케이션

문서 및 도구

EC27201F94CE0401
EC27201F94CE0402
EC27201F94CE0403
