ICLED EVO 3838

Current control up to 256 adjustment levels, brightness up to 7000 mcd. Superior color performance with 16-bit PWM tuning and precise calibration for rich, consistent colors.

More Downloads Request for Demo

Specifications

EV3838CMTCM20601

Product Type

 iCLeds

Dimension (L x W x H)

 3.8 x 3.8 X 0.85 mm

Operating Temperature

 -40° ~ 125℃

Beam Angle

 120 °

Emitting Color

Red (612-630 nm)

Green (565-575 nm)

Blue (450-480 nm)

White

Brightness

Electrical

Luminous Flux (Φv)

Red Typ. lm

Electrical Power

 Typ. 0.5 W

Green Typ. lm

Blue Typ. lm

White Typ. lm



Luminous Intensity(Iv)

Red Typ. 1200 mcd

Forward Current (IF)

Red Typ. 21 mA

Green Typ. 2720 mcd

Green Typ. 27 mA

Blue Typ. 142 mcd

Blue Typ. 11 mA

White Typ. 4000 mcd

White Typ. 55 mA

Benefits

  • Current control up to 256 adjustment levels, brightness up to 7000 mcd. Superior color performance with 16-bit PWM tuning and precise calibration for rich, consistent colors.

Applications

Ambient Lighting

Interior Lighting

Exterior Lighting

Related Products

TOP ICLED 3535

TOP ISELED 3233

ICLED 5050

Mini ICLED 1212

Documents & Tools

EV3838CMTCM20601
Datasheets

EV3838CMTCM20601
