Power TOP LED 1519

Power TOP LED 1519

Compact package with chip scale optical window for easily introducing and designing in automotive lighting application. Isolated thermal pad enables better thermal design.

More Downloads Request for Demo

Product Performance

Part Number

Emitter Color

Wavelength

Electrical Power

Forward

Current (IF)

Luminous

Flux (Φv)

Luminous

Intensity(Iv)
5F1519AW3FFMZQNG

White

-

1.5 W

500 mA

170 lm

- mcd

120 °
V51519W40WPZ1

White

-

1.5 W

500 mA

200 lm

- mcd

120 °
V51519W40WQZ1

White

-

3 W

1000 mA

390 lm

- mcd

120 °
5F1519AW5FFMZYNG

Amber

609-624 nm

1.5 W

500 mA

110 lm

- mcd

120 °

Product Information

Benefits

  • Compact package with chip scale optical window for easily introducing and designing in automotive lighting application.

    Isolated thermal pad enables better thermal design.

Features

AECQ102 qualified

MSL2 qualified according to JEDEC J-STD020

RoHS and REACH-compliant

Applications

Exterior Lighting

Related Products

TOP LED 1519

TOP LED 1608

TOP LED 3433 RGB

TOP LED 2720

Documents & Tools

5F1519AW3FFMZQNG
V51519W40WPZ1
V51519W40WQZ1
5F1519AW5FFMZYNG
