SIDE LED 5514

RoHS and REACH-compliant

MSL2a qualified according to JEDEC J-STD020

사양

PV55142V62T50601

제품 유형

 LED

치수 (L x W x H)

 5.5 x 1.4 X 1.6 mm

작동 온도

 -40° ~ 110℃

빔 각도

 120 °

이미터 색상

Red (612-630 nm)

밝기

전기

광속 (Φv)

Red Typ. 17 lm

전력

 Typ. 0.336 W



발광 강도(Iv)

Red Typ. 5411 mcd

순방향 전류 (IF)

Red Typ. 140 mA

혜택

  • Designed for automotive exterior applications, Side View LED 5514 features an ultra-thin, side-emitting design ideal for slim light guide plates and space-efficient lighting modules.

기능

RoHS and REACH-compliant

MSL2a qualified according to JEDEC J-STD020

문서 및 도구

PV55142V62T50601
