TOP LED 3030 RGB

Elevate your ambiance with our mid-power RGB LED, seamlessly coupling to light tube structures for vibrant lighting.

More Downloads Request for Demo

Specifications

V63030VGBMLN1

Product Type

 LED

Dimension (L x W x H)

 3 x 3 X 0.65 mm

Operating Temperature

 -40° ~ 125℃

Beam Angle

 120 °

Emitting Color

Red (612-630 nm)

Green (565-575 nm)

Blue (450-480 nm)

Brightness

Electrical

Luminous Flux (Φv)

Red Typ. 17 lm

Electrical Power

 Typ. 0.5 W

Green Typ. 44 lm

Blue Typ. 10 lm



Luminous Intensity(Iv)

Red Typ. - mcd

Forward Current (IF)

Red Typ. 150 mA

Green Typ. - mcd

Green Typ. 150 mA

Blue Typ. - mcd

Blue Typ. 150 mA

Benefits

  • Mid power RGB LED for ambient lighting with side coupling to a light tube structure.

Features

0.5W RGB, forward current: ≦ 250mA

Binning by RGB spec

AECQ102 qualified

MSL level 2a

RoHS2.0 and REACH-compliant

Applications

Interior Lighting
