TOP iCLed 2020

Compact RGB ICLED for consumer, automotive, and display applications.

Specifications

VC2020VGBCFN1

Product Type

 iCLed

Dimension (L x W x H)

 2 x 2 X 0.75 mm

Operating Temperature

 -40° ~ 105℃

Beam Angle

 120 °

Emitting Color

Red (612-630 nm)

Green (565-575 nm)

Blue (450-480 nm)

Brightness

Electrical

Luminous Flux (Φv)

Red Typ. - lm

Electrical Power

 Typ. 0.4 W

Green Typ. - lm

Blue Typ. - lm



Luminous Intensity(Iv)

Red Typ. 460 mcd

Forward Current (IF)

Red Typ. 20 mA

Green Typ. 1900 mcd

Green Typ. 20 mA

Blue Typ. 330 mcd

Blue Typ. 20 mA

Benefits

  • Compact RGB ICLED for consumer, automotive, and display applications.

Features

Compact top view RGB ICLED, 20mA per channel, 8 bits PWM, 5 bits brightness dimming

Dual line signal transmission, Data/Clock

Binning by RGB spec

Supports sleep /wake-up mode. In sleep mode, the LED's current was lower than 5uA

AECQ100/102 qualified

MSL level 3

RoHS Compliant
