Power Dome LED 3838 130°/150°
Specifically designed for Occupancy Monitor Systems and security purposes, ensuring unwavering reliability in demanding conditions.
Specifically designed for Occupancy Monitor Systems and security purposes, ensuring unwavering reliability in demanding conditions.
Product Type |
IR LED |
Dimension (L x W x H) |
3.85 x 3.85 X 1.51 mm |
Operating Temperature |
-40° ~ 105℃ |
Beam Angle |
150 ° |
Brightness |
Electrical |
||
Radiant Intensity(IE) |
215 mW/sr |
Forward Current (IF) |
Typ. 1000 mA |
Total Radiant Flux (ΦE) |
1000 mW |
Electrical Power |
Typ. 2 W |
Peak Wavelength(λP) |
940 nm |
Forward Voltage(vF) |
180 V |
An AEC Q102 Qualified solution, engineered with low thermal resistance, 2kV ESD protection, and certified Class 3B for corrosion robustness.
IR light source with high efficiency
Peak wavelength 940 nm
Single junction emitter
RoHS 2.0 and REACH compliant
MSL 2 qualified according to J STD 020
SJ3838F94CQ00 Instruction Manual Operation Manual.pdf
SJ3838F94CQ00 Spectrum .xlsx
SJ3838F94CQ00.1.ent.zip
SJ3838F94CQ00_10000000Rays_ASAP.dis
SJ3838F94CQ00_10000000Rays_FRED.ray
SJ3838F94CQ00_10000000Rays_IESTM25.tm25ray
SJ3838F94CQ00_10000000Rays_LightTools.ray
SJ3838F94CQ00_10000000Rays_LUCID.ray
SJ3838F94CQ00_10000000Rays_OPTIS.ray
SJ3838F94CQ00_10000000Rays_TraceProBinary.ray
SJ3838F94CQ00_10000000Rays_ZEMAX.dat
SJ3838F94CQ00_5000000Rays_ASAP.dis
SJ3838F94CQ00_5000000Rays_FRED.ray
SJ3838F94CQ00_5000000Rays_IESTM25.tm25ray
SJ3838F94CQ00_5000000Rays_LightTools.ray
SJ3838F94CQ00_5000000Rays_LUCID.ray
SJ3838F94CQ00_5000000Rays_OPTIS.ray
SJ3838F94CQ00_5000000Rays_TraceProBinary.ray
SJ3838F94CQ00_5000000Rays_ZEMAX.dat
